Stuart Turner Ch Single Stage Auto Flow Switch 9-14 Fl – 46387

The Monsoon Extra Standard 1.4 bar max single pump is designed for use in larger domestic and light commercial applications. Installed into an open vented hot or cold water system, where all outlets are below the level of the cold water cistern, it has the equivalent effect of raising the cold water cistern 13 metres above its current position with a flow rate of 45 litres per minute.



Applications include boosting water pressures to individual outlets where a medium pressure is required. The pump is not recommended for use in pairs boosting common hot and cold supplies to mixer taps and shower valves (for applications such as this please refer to the Monsoon Extra Universal range). The Monsoon Extra Standard 1.4 bar max single is ideal as an outlet pump installed after a shower valve pumping to multiple shower heads in leisure centres and schools.
